Suzuki SX4 I (2006-2009) rear acc socket Wiring diagram
This page shows the only wiring diagram for the component.rear acc socket, which is found in the car Suzuki SX4 I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear acc socket (1 of 1)
ACC 2 FUSE
BCM
BLK WIRE
BLOWER FAN RELAY
BLU WIRE
BRAKE LIGHT SWITCH
D/L FUSE RR DEF FUSE
ECM, TCM
FLASHER RELAY
FROM IGNITION SWITCH (DIAGRAM 1 OF 2)
FROM INDIVIDUAL CIRCUIT
FROM MAIN FUSE BOX (DIAGRAM 1 OF 2)
FROM RR DEF FUSE (DIAGRAM 2 OF 2)
FROM WIP FUSE (DIAGRAM 1 OF 2)
FRONT FOG LIGHT SWITCH
FUSE
FUSE BOX 1 (DIAGRAM 1 OF 2)
GRN WIRE
HORN HAZ FUSE DOME FUSE FROM HORN RELAY (DIAGRAM 2 OF 2)
HORN RELAY
KLS ECM, MULTI INFORMATION DISPLAY, AUDIO
LUGGAGE COMPARTMENT LIGHT
MODULE
ORG/ WIRE
P/W FUSE FUSE
POWER MIRROR SWITCH
REAR ACC SOCKET
RED WIRE
RR DEF RELAY
SOCKET
STOP FUSE AUDIO FUSE
TAIL FUSE 10
TAIL LIGHT RELAY
TO HORN HAZ FUSE (DIAGRAM 2 OF 2)
WHT WIRE
WOOFER
YEL WIRE
Go to component -> Power distribution circuit (2 of 2) -> REAR ACC SOCKET
