Suzuki SX4 I (2006-2009) left headlight high relay Wiring diagram
This page shows the only wiring diagram for the component.left headlight high relay, which is found in the car Suzuki SX4 I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left headlight high relay (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
BRN WIRE
COMBINATION SWITCH DIMMER/ PASSING SWITCH
FR FOG FUSE
FRONT FOG LIGHT RELAY (LEFT SIDE OF DASH)
FRONT FOGLAMP SWITCH
GRN WIRE
GRN/WHT WIRE
GRY/RED WIRE
HIGH BEAM IND
HOT AT ALL TIMES
INDIVIDUAL CIRCUIT FUSE BOX 1
INSTRUMENT CLUSTER
JUNCTION BLOCK ASSEMBLY (LEFT SIDE OF DASH)
LEFT FRONT FOG LAMP
LEFT H/L FUSE
LEFT HEADLIGHT
LEFT HEADLIGHT HIGH RELAY
LEFT HEADLIGHT LOW RELAY (LEFT SIDE OF ENGINE COMPT)
LIGHT SWITCH TAIL HEAD OFF
LO FLASH UP
LT GRN WIRE
MTR FUSE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT FRONT FOG LAMP
RIGHT H/L FUSE
RIGHT HEADLIGHT
RIGHT HEADLIGHT HIGH RELAY
RIGHT HEADLIGHT LOW RELAY (LEFT SIDE OF ENGINE COMPT)
TAIL FUSE
TAIL LIGHT RELAY
W/ ILL CANCEL SWITCH
W/O ILL CANCEL SWITCH
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Headlights circuit -> LEFT HEADLIGHT HIGH RELAY
