Suzuki Swift II facelift (1995-2003) Anti-lock brake circuits

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 PPL ABS ACTIVE IND. ABS CHECK RELAY (BEHIND DASH, LEFT OF STEERING COLUMN) ABS ENABLE RELAY (IN FUSE/RELAY BOX) ABS IND. ABS MOTOR PACK (LEFT REAR CORNER OF ENGINE COMPARTMENT) BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE IND BRAKELIGHT SWITCH (ON TOP OF BRAKE PEDAL BRACKET) BRN WIRE BRN/BLK WIRE COMBINATION METER DATA LINK COUPLER (PARTIAL) (BELOW DASH RIGHT OF STEERING COLUMN) EBCM (ABS CONTROL MODULE) (BEHIND DASH, LEFT OF STEERING COLUMN) FUSE 12 FUSE 18 FUSE 19 FUSE 21 FUSE BOX (ON LEFT FRONT INNER FENDER PANEL, BEHIND FUSE/RELAY BOX) FUSE 3 GRN WIRE GRN/BLK WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON HOT IN ON OR START JUNCTION FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) JUNCTION FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) FUSE 23 LEFT ABS SOLENOID (LEFT SIDE OF FIREWALL) LEFT FRONT SPEED SENSOR RIGHT FRONT SPEED SENSOR LEFT REAR SPEED SENSOR LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE PNK/BLK WIRE PPL RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT ABS SOLENOID (LEFT SIDE OF FIREWALL) RIGHT REAR SPEED SENSOR WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
