Car Wiring Diagrams for Warning system circuits for Suzuki Sidekick I (1988-1998)

BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLU/BLK WIRE COMBINATION METER FUSE 11 FUSE 16 GRY/RED WIRE HEADLIGHT RELAY 2 (RIGHT SIDE OF RADIO) HOT AT ALL TIMES HOT IN ON AND START FUSE BLOCK (UNDER LEFT SIDE OF DASH) JUNCTION CONNECTOR (BEHIND GLOVE BOX) JUNCTION CONNECTOR (LEFT END OF DASH) JUNCTION CONNECTOR (RIGHT SIDE OF RADIO) KEY REMINDER SWITCH (IGNITION SWITCH) LEFT FRONT DOOR SWITCH LEFT FRONT DOOR SWITCH (SIDEKICK) NCA WIRE RED/YEL WIRE SEAT BELT SEAT BELT SWITCH SIDEKICK WARNING CONTROLLER (BEHIND DASH, ABOVE RIGHT FRONT SPEAKER) WHT WIRE YEL/RED WIRE
