1.6l, 3 speed a/t circuit for Suzuki Sidekick I (1988-1998)
1.6l, 3 speed a/t circuit
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
ENGINE CONTROL MODULE (LEFT OF STEERING COLUMN) TCC RELAY CONTROL
FUSE 16
FUSE 7
FUSE BOX
HOT AT ALL TIMES
HOT IN ON, START
MAIN FUSE
MAIN RELAY (UNDER CENTER OF DASH, BEHIND BLOWER SELECTOR SWITCH)
MAIN RELAY CONTROL
TORQUE CONVERTER CLUTCH (TCC) SOLENOID (TRANSMISSION)
WHT WIRE
WHT/YEL WIRE
