Supplemental restraint circuit for Suzuki Sidekick I (1988-1998)
Supplemental restraint circuit
AIR BAG FUSE BOX FUSE 32
AIRBAG INDICATOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
COMBINATION METER
CONTACT COIL
DATA LINK CONNECTOR
DIAGNOSIS CONNECTOR (LEFT SIDE OF DASH UNDERSIDE OF STEERING COLUMN)
DRIVER'S INFLATOR MODULE
FUSE 16
FUSE BOX
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT IN ON OR START
J/C (LEFT SIDE OF I/P)
J/C (LEFT SIDE OF I/P) (1.8L ONLY)
NCA WIRE
PASSENGER INFLATOR MODULE
RED GRN/ WIRE
RED WIRE
RED/BLK WIRE
SDM (UNDER CENTER OF DASH)
SEAT BELT SWITCH (IN BUCKLE)
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
