1.6l, power door lock circuit for Suzuki Sidekick I (1988-1998)

1.6l, power door lock circuit

Get access

1 2 1 3 (NOT USED) 4 DOOR BACK DOOR MOTOR, LATCH SWITCH BLK WIRE BLU (OR GRN/WHT) WIRE BLU (OR GRN/YEL) WIRE BLU WIRE BLU/BLK WIRE BLU/RED (OR GRN/YEL) WIRE BLU/RED WIRE BLU/YEL WIRE DOOR LOCK CONTROLLER (LEFT SIDE OF DASH) DRIVER'S DOOR LATCH SWITCH, MOTOR DRIVER'S DOOR LOCK MAIN SWITCH FUSE 14 FUSE BOX HOT AT ALL TIMES LEFT REAR DOOR MOTOR (4 DOOR) PASSENGER'S DOOR LATCH SWITCH, MOTOR PNK (NOT USED) WIRE PNK WIRE PNK/BLK WIRE RED WIRE RIGHT REAR DOOR MOTOR (4 DOOR)
