Power windows circuit, with front & rear power windows for Suzuki Reno I (2004-2008)
Power windows circuit, with front & rear power windows
BLK WIRE
BLU WIRE
BRN WIRE
CONTROLLER
DOWN
DOWN UP
ENGINE ROOM FUSE, RELAY BLOCK (LEFT FRONT OF ENGINE COMPT)
FUSE 14
FUSE 6
FUSE 9
GRN WIRE
HOT AT ALL TIMES
HOT IN ON
I/P FUSE BLOCK (LEFT END OF DASH)
LEFT "C" PILLAR)
LEFT FRONT POWER WINDOW MOTOR (IN LEFT FRONT DOOR)
LEFT REAR POWER WINDOW MOTOR (IN LEFT REAR DOOR)
LEFT REAR SUB- SWITCH
LOCK UN- LOCK
LT GRN WIRE
ORG/ WIRE
POWER WINDOW RELAY
POWER WINDOW SWITCH
RED WIRE
RIGHT FRONT POWER WINDOW MOTOR (IN RIGHT FRONT DOOR)
RIGHT FRONT SUB- SWITCH
RIGHT REAR POWER WINDOW MOTOR (IN RIGHT REAR DOOR)
RIGHT REAR SUB- SWITCH
VIO WIRE
WHT WIRE
