Suzuki Reno I (2004-2008) ssps warning indicator Wiring diagram
This page shows the only wiring diagram for the component.ssps warning indicator, which is found in the car Suzuki Reno I (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ssps warning indicator (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 LOW HIGH
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
ENGINE FUSE BLOCK (LEFT FRONT OF ENGINE COMPT)
FUSE 2
FUSE 4
GRN/WHT WIRE
GROUND
GRY WIRE
HOT IN ON OR START
I/P FUSE BLOCK (LEFT END OF DASH)
INSTRUMENT CLUSTER
LT BLU WIRE
LT GRN WIRE
MICRO -
PNK IGN+ GROUND GROUND WIRE
PNK PNK WIRE
PNK WIRE
PNK/BLU WIRE
PPL
SIGNAL
SPEED SENSITIVE POWER STEERING CONTROL MODULE (SSPS) (UNDER RIGHT SIDE OF DASH)
SSPS ACTUATOR
SSPS WARNING INDICATOR
STEERING WHEEL SENSOR
TCM (TRANSMISSION CONTROL MODULE) (BEHIND LEFT SIDE OF DASH)
VEHICLE SPEED SENSOR (VSS) (M/T) (LEFT REAR OF ENGINE)
VIO WIRE
Go to component -> Electronic power steering circuit -> SSPS WARNING INDICATOR
