Suzuki Reno I (2004-2008) front fog switch Wiring diagrams
This page contains all the electrical diagrams for the component. front fog switch, in which he is found in the car Suzuki Reno I (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
front fog switch wiring diagram (1 of 2)
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CLUSTER
DRL RELAY
ENGINE ROOM FUSE, RELAY BLOCK (LEFT FRONT OF ENGINE COMPT) FUSE 24
FOG LAMP RELAY
FRONT FOG SWITCH
FUSE 28
GRN WIRE
HOT AT ALL TIMES
HOT W/ ILLUMINATION RELAY ENERGIZED
I/P FUSE BLOCK (LEFT END OF DASH)
LEFT FRONT FOG LAMP
LT GRN WIRE
RIGHT FRONT FOG LAMP
SPLICE PACK 201 (BEHIND INSTRUMENT CLUSTER)
SPLICE PACK 204 (BEHIND CENTER OF DASH)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Fog lamps circuit -> FRONT FOG SWITCH
front fog switch wiring diagram (2 of 2)
BLK WIRE
BRAKE FLUID SWITCH (ON BRAKE MASTER CYLINDER)
BRN WIRE
BRN/WHT WIRE
DIMMER SWITCH
DIODE
DRL MODULE
DRL RELAY
ENGINE ROOM FUSE, FUSE 15 RELAY BLOCK (LEFT FRONT OF ENGINE COMPT)
ENGINE ROOM FUSE, RELAY BLOCK (LEFT FRONT OF ENGINE COMPT) FUSE 28
FRONT FOG SWITCH
FUSE 12
FUSE 20
FUSE 27
FUSE 6
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HEAD PARK
HEADLAMP RELAY
HEADLAMP SWITCH
HIGH LOW
HOT AT ALL TIMES
HOT IN ON
HOT W/ ILLUMINATION RELAY ENERGIZED
I/P FUSE BLOCK (LEFT END OF DASH)
INSTRUMENT CLUSTER SYSTEM
LEFT HEAD- LAMP
LIGHT SWITCH
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OFF
OFF HEAD PARK
ORG/ WIRE
PARKING BRAKE SWITCH (UNDER CENTER CONSOLE)
PASSING SWITCH
RIGHT HEAD- LAMP
SPLICE PACK 201 (BEHIND INSTRU- MENT CLUSTER)
SPLICE PACK 201 (BEHIND INSTRUMENT CLUSTER)
SPLICE PACK 203 (BEHIND CENTER OF DASH)
SPLICE PACK 204 (BEHIND CENTER OF DASH)
SPLICE PACK 301 (BEHIND LEFT KICK PANEL)
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Headlamps circuit -> FRONT FOG SWITCH
