Navigation circuit, with audio amplifier for Suzuki Kizashi I (2009-2014)

1 2 3 4 5 NAVI- GATION SYSTEM (REAR VIEW CAMERA CIRCUIT) ANTENNA ANTENNA AMPLIFIER ANTENNA AMPLIFIER (XM SATELLITE) (IF EQUIPPED) ANTENNA BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH) BRN WIRE CONTACT COIL ASSEMBLY (TOP OF STEERING COLUMN) FUSE GPS ANTENNA GRN WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED J/C JUNCTION BLOCK (J/B) (LEFT SIDE LT GRN WIRE MICRO PHONE (CONSOLE) (IF EQUIPPED) MODE NAVIGATION NCA WIRE OF DASH) PNK WIRE PNK/BLK WIRE PNK/GRN WIRE PPL PPL PNK WIRE PPL PPL RADIO FUSE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE SEEK + SEEK - STEERING SWITCH (REMOTE AUDIO CONTROL SWITCH) TV ANTENNA TV ANTENNA AMPLIFIER USB SOCKET VOL (-) VOL+ ENTER WHT WIRE WHT/RED WIRE

AUDIO AMPLIFIER (RIGHT SIDE OF TRUNK) AUDIO BOX 2 FUSE BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE CENTER SPEAKER GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES J/C LEFT FRONT SPEAKER LEFT REAR SPEAKER LEFT RIGHT TWEETER TWEETER LT GRN WIRE NCA WIRE RED WIRE RED/BLU WIRE RELAY RIGHT FRONT SPEAKER RIGHT REAR SPEAKER WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WOOFER (IF EQUIPPED) YEL WIRE
