Suzuki Kizashi I (2009-2014) Courtesy lamps circuit

BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/YEL WIRE CONTROL MODULE DIODE DOME FUSE DRIVER SIDE COURTESY LIGHT DRIVER SIDE FRONT DOOR SWITCH FRONT DOME LIGHT GLOVE BOX LIGHT GLOVE BOX LIGHT SWITCH GRN/ORG WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES J/C JUNCTION BLOCK (LEFT SIDE OF DASH) KEYLESS START CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) LEFT FOOT LIGHT LEFT REAR DOOR SWITCH LEFT VANITY LIGHT OFF OFF ON DR ON ON PASSENGER SIDE COURTESY LIGHT PASSENGER SIDE FRONT DOOR SWITCH REAR DOME LIGHT RED/WHT WIRE RED/YEL WIRE RIGHT FOOT LIGHT RIGHT REAR DOOR SWITCH RIGHT VANITY LIGHT SPOT LIGHT SPOT LIGHT, FRONT DOME LIGHT TRUNK LID OPENER ACTUATOR (CENTER REAR OF TRUNK) TRUNK LIGHT WHT WIRE WHT/RED WIRE
