Suzuki Kizashi I (2009-2014) left side marker light Wiring diagrams

AUTO A/C PANEL BCM (RIGHT SIDE OF DASH) BLK WIRE BLU WIRE BLU/BLK WIRE COMBINATION SWITCH GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HAZ FUSE HAZARD SWITCH HEAD HOT AT ALL TIMES HOT AT ALL TIMES TAIL FUSE J/C JUNCTION BLOCK (J/B) (LEFT SIDE OF DASH) LEFT CLEAR- ANCE LIGHT LEFT SIDE MARKER LIGHT LEFT TAIL LIGHT LICENSE PLATE LIGHT 1 LICENSE PLATE LIGHT 2 LIGHT SWITCH RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT CLEAR- ANCE LIGHT RIGHT SIDE MARKER LIGHT RIGHT TAIL LIGHT TAIL TAIL LIGHT RELAY TURN SIGNAL SWITCH OFF WHT WIRE YEL WIRE YEL/RED WIRE

A/B SDM ACC SOCKET 1 ACC SOCKET 2 (EARLY PRODUCTION, LATE PRODUCTION ACC SOCKET 2 (W/ AUDIO AMPLIFIER) ACCESSORY RELAY ACCESSORY SOCKET 2 (LATE PRODUCTION AMPLIFIER AUDIO AUDIO (2013 MODEL) AUDIO AMPLIFIER) HIGH MOUNTED STOP LIGHT PARKING SENSOR SYSTEM CONTROL MODULE AUTO A/C PANEL AUTO DIMMING REARVIEW MIRROR AUTO STEERING LOCK UNIT BATTERY BLK WIRE BLK/WHT WIRE BLOWER MOTOR CONTROLLER BLOWER MOTOR RELAY BRAKE FLUID LEVEL SWITCH CKP SENSOR CMP SENSOR COMBINATION METER COMBINATION SWITCH CONTACT COIL ASSEMBLY CONTROL MODULE (W/ AUDIO AMPLIFIER) CONTROL MODULE (W/O AUDIO AMPLIFIER) CPP CUT SWITCH (M/T) CPP SWITCH (M/T) CVT RELAY DATA LINK CONNECTOR DLC DRIVER SIDE LUMBAR SUPPORT SWITCH DRIVER SIDE POWER DOOR LOCK ASSEMBLY DRIVER SIDE POWER MIRROR ASSEMBLY DRIVER SIDE REQUEST SWITCH DRIVER SIDE SEAT HEATER DRL CONTROL MODULE ENGINE SWITCH ESP CONTROL MODULE ESP OFF SWITCH EVAP LEAK CHECK MODULE (IF EQUIPPED) DRIVER SIDE DOOR LOCK SWITCH FUEL PUMP, FUEL GAUGE GRY WIRE HAZARD SWITCH HIGH MOUNTED STOP LIGHT HOOD LATCH SWITCH HVAC CONTROL MODULE IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 J/C JUNCTION BLOCK (J/B) KEYLESS START CONTROL MODULE LATE PRODUCTION W/ AUDIO AMPLIFIER LEFT BACKUP LIGHT LEFT BRAKE LIGHT LEFT CLEARANCE LIGHT LEFT FRONT FOG LIGHT LEFT FRONT POWER WINDOW MOTOR LEFT FRONT TURN SIGNAL LIGHT LEFT HEADLIGHT LEFT REAR TURN SIGNAL LIGHT LEFT SIDE MARKER LIGHT LEFT SIDE TURN SIGNAL LIGHT LEFT TAIL LIGHT LICENSE PLATE LIGHT 1 LICENSE PLATE LIGHT 2 NAVIGATION NAVIGATION (2013 MODEL) OUTSIDE WARNING BUZZER P/S CONTROL MODULE PASSENGER SIDE DOOR LOCK SWITCH PASSENGER SIDE POWER MIRROR ASSEMBLY PASSENGER SIDE REQUEST SWITCH PASSENGER SIDE SEAT HEATER POWER MIRROR SWITCH POWER SEAT CONTROL MODULE POWER SEAT SUB SWITCH POWER WINDOW MASTER SWITCH POWER WINDOW SUB-SWITCH RADIATOR COOLING FAN RELAY 2 RADIATOR FAN MOTOR 2 RAIN/LIGHT SENSOR REAR DEFOGGER RELAY RIGHT BACKUP LIGHT RIGHT BRAKE LIGHT RIGHT CLEARANCE LIGHT RIGHT END OF DASH) RIGHT FRONT FOG LAMP RIGHT FRONT POWER WINDOW MOTOR RIGHT FRONT TURN SIGNAL LIGHT RIGHT HEADLIGHT RIGHT REAR TURN SIGNAL LIGHT RIGHT SIDE MARKER LIGHT MIRROR HEATER RELAY RIGHT SIDE TURN SIGNAL LIGHT RIGHT TAIL LIGHT SEAT BELT SWITCH SELECT LEVER ASSEMBLY SPOT LIGHT, FRONT DOME LIGHT JUNCTION STEERING ANGLE SENSOR SUNROOF SWITCH SUNROOF UNIT SWITCH TCM, ECM TRANSAXLE RANGE SENSOR (A/T) TRUNK LID OPENER ACTUATOR TRUNK LID OPENER ACTUATOR TRUNK LID REQUEST SWITCH TRUNK LID OPENER CANCEL SWITCH TRUNK LID OPENER SWITCH TURN SIGNAL SWITCH TRUNK LID REQUEST SWITCH WHT WIRE WINDSHIELD WIPER/ WASHER SWITCH WIPER MOTOR YEL WIRE

AUTO A/C PANEL AWD SWITCH BLK WIRE BLK/ BLU WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH) COMBINATION METER CONSOLE LIGHT CONTACT COIL ASSEMBLY (TOP OF STEERING COLUMN) ESP OFF SWITCH FRONT FOG LIGHT SWITCH GRN WIRE HOT AT ALL TIMES J/C JUNCTION BLOCK (LEFT SIDE OF DASH) LEFT CLEARANCE RANCE LIGHT LEFT REAR POWER WINDOW SUB SWITCH LEFT SIDE MARKER LIGHT LEFT TAIL LIGHT LICENSE PLATE LIGHT 1 LICENSE PLATE LIGHT 2 LIGHT SWITCH COMBINATION SWITCH LT GRN/BLK WIRE NAVIGATION (W/ NAVIGATION) AUDIO (W/O NAVIGATION) NCA WIRE POWER MIRROR SWITCH POWER WINDOW SUB POWER WINDOW MASTER SWITCH SWITCH RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT CLEA- RANCE LIGHT RIGHT REAR POWER WINDOW SUB SWITCH RIGHT SIDE MARKER LIGHT RIGHT TAIL LIGHT SELECT LEVER ASSEMBLY STEERING SWITCH TAIL FUSE TAIL LIGHT RELAY TRUNK LID OPENER SWITCH W/O PARKING SENSOR SYSTEM W/ PARKING SENSOR SYSTEM YEL BLK/ WIRE YEL RED/ WIRE
