Suzuki Kizashi I (2009-2014) left clearance rance light Wiring diagram
This page shows the only wiring diagram for the component.left clearance rance light, which is found in the car Suzuki Kizashi I (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left clearance rance light (1 of 1)
AUTO A/C PANEL
AWD SWITCH
BLK WIRE
BLK/ BLU WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH)
COMBINATION METER
CONSOLE LIGHT
CONTACT COIL ASSEMBLY (TOP OF STEERING COLUMN)
ESP OFF SWITCH
FRONT FOG LIGHT SWITCH
GRN WIRE
HOT AT ALL TIMES
J/C
JUNCTION BLOCK (LEFT SIDE OF DASH)
LEFT CLEARANCE RANCE LIGHT
LEFT REAR POWER WINDOW SUB SWITCH
LEFT SIDE MARKER LIGHT
LEFT TAIL LIGHT
LICENSE PLATE LIGHT 1
LICENSE PLATE LIGHT 2
LIGHT SWITCH COMBINATION SWITCH
LT GRN/BLK WIRE
NAVIGATION (W/ NAVIGATION) AUDIO (W/O NAVIGATION)
NCA WIRE
POWER MIRROR SWITCH
POWER WINDOW SUB POWER WINDOW MASTER SWITCH SWITCH
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT CLEA- RANCE LIGHT
RIGHT REAR POWER WINDOW SUB SWITCH
RIGHT SIDE MARKER LIGHT
RIGHT TAIL LIGHT
SELECT LEVER ASSEMBLY
STEERING SWITCH
TAIL FUSE
TAIL LIGHT RELAY
TRUNK LID OPENER SWITCH
W/O PARKING SENSOR SYSTEM W/ PARKING SENSOR SYSTEM
YEL BLK/ WIRE
YEL RED/ WIRE
Go to component -> Instrument illumination circuit -> LEFT CLEARANCE RANCE LIGHT
