Suzuki Kizashi I (2009-2014) int/ auto lo mist hi off int volume Wiring diagram
This page shows the only wiring diagram for the component.int/ auto lo mist hi off int volume, which is found in the car Suzuki Kizashi I (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram int/ auto lo mist hi off int volume (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
EVAPORATOR TEMPERATURE
FR WIP FUSE WIP FUSE
FUSE
GRY/GRN WIRE
HOT IN ON
INT/ AUTO LO MIST HI OFF INT VOLUME
J/C
JUNCTION BLOCK (J/B) (LEFT SIDE OF DASH)
LO HI
LT GRN WIRE
OFF ON
PNK WIRE
PPL/RED WIRE
RED WIRE
RED/GRN WIRE
SENSOR (RIGHT CENTER OF DASH)
WASHER MOTOR
WASHER SWITCH
WHT WIRE
WIPER HI/LO RELAY (MAIN FUSE, RELAY BOX)
WIPER MOTOR (ENGINE COMPT COWL)
WIPER/ WASHER SWITCH
YEL WIRE
YEL/RED WIRE
Go to component -> Wiper/washer circuit -> INT/ AUTO LO MIST HI OFF INT VOLUME
