Suzuki Kizashi I (2009-2014) cvt shift lock solenoid Wiring diagram
This page shows the only wiring diagram for the component.cvt shift lock solenoid, which is found in the car Suzuki Kizashi I (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cvt shift lock solenoid (1 of 1)
BCM FUSE
BLK WIRE
BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH)
BRAKE LIGHT SWITCH (BRAKE PEDAL)
CVT SHIFT LOCK SOLENOID
GRN/WHT WIRE
HOT AT ALL TIMES
J/B
J/C
JUNCTION BLOCK (J/B) (LEFT SIDE OF DASH)
KEYLESS START CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
MODULE (RIGHT SIDE OF TRUNK)
PNK/BLK WIRE
PNK/GRN WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
SELECT LEVER ASSEMBLY POSITION SWITCH
STOP FUSE
WHT WIRE
WHT/BLK WIRE
Go to component -> Shift interlock circuit -> CVT SHIFT LOCK SOLENOID
