Suzuki Kizashi I (2009-2014) cpp cut switch Wiring diagram
This page shows the only wiring diagram for the component.cpp cut switch, which is found in the car Suzuki Kizashi I (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cpp cut switch (1 of 1)
APP SENSOR (ACCELERATOR PEDAL)
ASSEMBLY (TOP OF STEERING COLUMN)
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRAKE LIGHT SWITCH (BRAKE PEDAL)
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
CANCEL ON/OFF
CLOSE
CLOSE OPEN
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONTACT COIL
CPP CUT SWITCH
CRUISE CONTROL SWITCH
CRUISE FUSE
CRUISE IND
CRUISE SET IND
ELECTRIC THROTTLE BODY ASSEMBLY (INTAKE MANIFOLD)
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROLS SYSTEM
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES RELAY BOX 1 FI FUSE
HOT IN ON OR START
IG-COIL FUSE
J/B (LEFT SIDE OF DASH)
J/C
LT GRN WIRE
M/T
MAIN
MAIN RELAY (MAIN FUSE, RELAY BOX)
MTR FUSE
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
OUTPUT SHAFT SPEED SENSOR (CVT)
PPL
PPL/RED WIRE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RESUME/ ACCEL
SET/ COAST
STEERING SWITCH
STOP FUSE
SUB +
TCM (RIGHT SIDE OF DASH)
THR MOT FUSE
THROTTLE ACTUATOR
THROTTLE ACTUATOR CONTROL RELAY (MAIN FUSE, RELAY BOX)
THROTTLE POSITION SENSOR
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Cruise control circuit -> CPP CUT SWITCH
