Transmission circuit for Suzuki Forenza I (2003-2008)

BLK WIRE BLK/WHT WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE SWITCH BRN WIRE BRN/WHT WIRE DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) ELECTRONIC THROTTLE CONTROL ENGINE CONTROL MODULE (ECM) (CENTER REAR OF ENGINE COMPT) ENGINE ROOM FUSE, RELAY BLOCK (LEFT FRONT OF ENGINE COMPT) FUSE 13 FUSE 2 GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY WIRE HOLD MODE SWITCH HOT AT ALL TIMES HOT IN ON ON START I/P FUSE BLOCK (LEFT END OF DASH) LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE ORG/ WIRE ORG/BLK WIRE PNK PNK WIRE PNK WIRE RED/BLU WIRE SOLENOID 1 SOLENOID 2 SOLENOID 3 SOLENOID 4 SOLENOID 5 SOLENOID 6 TRANSAXLE TRANSMISSION CONTROL MODULE (TCM) (BEHIND LEFT SIDE OF DASH) TRANSMISSION FLUID TEMPER- ATURE SENSOR VIO WIRE WHT/BLK WIRE WHT/BRN WIRE YEL WIRE YEL/BLK WIRE

BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE FUSE 4 GRN/WHT WIRE HOLD MODE IND HOT IN ON OR START I/P FUSE BLOCK (LEFT END OF DASH) INPUT SPEED SENSOR (ISS) INSTRUMENT CLUSTER LT GRN/BLK WIRE LT GRN/RED WIRE MICOM OUTPUT SPEED SENSOR (OSS) P R N D 3 2 1 PNK WIRE PNP SWITCH) RED/BLU WIRE SPEEDO- METER YEL WIRE YEL/BLK WIRE
