Power door locks circuit for Suzuki Forenza I (2003-2008)
Power door locks circuit
2 8 LOCK
ANTI-THEFT CONTROL UNIT (UNDER FLOOR CONSOLE)
BLK WIRE
CENTRAL DOOR LOCK UNIT
DOOR LOCK SWITCH
ENGINE ROOM FUSE, RELAY BLOCK (LEFT FRONT OF ENGINE COMPARTMENT)
FUSE 26
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT CENTRAL LOCKING, ANTI-THEFT SWITCH
LEFT FRONT DOOR ACTUATOR (REAR OF LEFT FRONT DOOR)
LEFT REAR DOOR ACTUATOR (REAR OF LEFT REAR DOOR)
LOCK UN- LOCK
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN/WHT WIRE
ORG/ WIRE
ORG/BLK WIRE
RIGHT FRONT DOOR ACTUATOR (REAR OF RIGHT FRONT DOOR)
RIGHT REAR DOOR ACTUATOR (REAR OF RIGHT REAR DOOR)
TAIL GATE ACTUATOR (LEFT SIDE OF TAILGATE DOOR) (EXCEPT NOTCHBACK)
UN LOCK
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
