Instrument illumination circuit for Suzuki Forenza I (2003-2008)
Instrument illumination circuit
A/C CONTROL SWITCH
ASHTRAY LAMP
AUDIO
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CLOCK
DIMMER CONTROL UNIT
ENGINE FUSE BLOCK (LEFT FRONT OF ENGINE COMPT)
FUSE 12
FUSE 28
GRN WIRE
HAZARD SWITCH
HOLD MODE SWITCH
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT END OF DASH)
ILLUMINATION RELAY
INSTRUMENT CLUSTER
LIGHT SWITCH
PARK HEAD OFF
PRNDL SWITCH
WHT WIRE
