Courtesy lamps circuit for Suzuki Forenza I (2003-2008)
Courtesy lamps circuit
1 2 (W/ SUNROOF) (W/O SUNROOF)
ANTI-THEFT SYSTEM
BLK WIRE
CONTROLLER IC
DOOR ON OFF
ENGINE FUSE BLOCK (LEFT FRONT OF ENGINE COMPT)
FUSE 19
FUSE 20
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P FUSE BLOCK (LEFT END OF DASH)
KEY ILLUMI- NATION
LEFT "C" PILLAR)
LEFT FRONT DOOR CONTACT SWITCH
LEFT REAR DOOR CONTACT SWITCH (LEFT "C" PILLAR)
MAP LAMP
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PNK/ (HATCHBACK, STATION WAGON) (NOTCHBACK) 2 3 WIRE
RIGHT FRONT DOOR CONTACT SWITCH (RIGHT "B" PILLAR)
RIGHT REAR DOOR CONTACT SWITCH (RIGHT "C" PILLAR)
ROOM LAMP (CENTER)
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
