Electronic power steering circuit for Suzuki Forenza I (2003-2008)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 LOW HIGH BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/BLK WIRE DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) ENGINE FUSE BLOCK (LEFT FRONT OF ENGINE COMPT) FUSE 2 FUSE 4 GRN/WHT WIRE GROUND GRY WIRE HOT IN ON OR START I/P FUSE BLOCK (LEFT END OF DASH) INSTRUMENT CLUSTER LT BLU WIRE LT GRN WIRE MICRO - PNK IGN+ GROUND GROUND WIRE PNK PNK WIRE PNK WIRE PNK/BLU WIRE PPL SIGNAL SPEED SENSITIVE POWER STEERING CONTROL MODULE (SSPS) (UNDER RIGHT SIDE OF DASH) SSPS ACTUATOR SSPS WARNING INDICATOR STEERING WHEEL SENSOR TCM (TRANSMISSION CONTROL MODULE) (BEHIND LEFT SIDE OF DASH) VEHICLE SPEED SENSOR (VSS) (M/T) (LEFT REAR OF ENGINE) VIO WIRE
