Cooling fan circuit for Suzuki Forenza I (2003-2008)
Cooling fan circuit
A/C PRESSURE TRANSDUCER (RIGHT SIDE OF ENGINE COMPT)
AIR CONDITIONING SYSTEM
BLK WIRE
BLU WIRE
COOLING FAN AUX (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN CONTROL RELAY (IN ENGINE ROOM FUSE BLOCK)
COOLING FAN HIGH RELAY
COOLING FAN LOW RELAY
COOLING FAN MAIN (BEHIND LEFT SIDE OF RADIATOR)
ENGINE CONTROL MODULE (ECM) (CENTER REAR OF ENGINE COMPT)
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (FRONT OF ENGINE)
ENGINE ROOM FUSE, RELAY BLOCK (LEFT FRONT OF ENGINE COMPT)
FUSE 21
FUSE 6
FUSE 8
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ MAIN RELAY ENERGIZED
LT BLU WIRE
LT GRN WIRE
LT LT
PNK/BLK WIRE
SPLICE PACK 101 (IN ENGINE ROOM HARNESS, NEAR TOP OF TRANSMISSION)
VIO WIRE
VIO/WHT WIRE
WHT WIRE
