Computer data lines circuit for Suzuki Forenza I (2003-2008)
Computer data lines circuit
AIR BAG CONTROL MODULE (SDM) (UNDER CENTER CONSOLE)
ANTI-THEFT CONTROL UNIT (UNDER FLOOR CONSOLE)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
EBCM (ABS MODULE) (LEFT REAR CORNER OF ENGINE COMPT)
ENGINE CONTROL MODULE (ECM) (CENTER REAR OF ENGINE COMPARTMENT)
FUSE 16
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT END OF DASH)
LT BLU WIRE
LT GRN WIRE
OIL FEEDING CONNECTOR (LEFT REAR OF ENGINE COMPT, NEAR ECBM)
ORG/ WIRE
SPEED SENSITIVE POWER STEERING CONTROL MODULE (SSPS) (UNDER LEFT SIDE OF DASH)
TRANSMISSION CONTROL MODULE (TCM) (BEHIND LEFT SIDE OF DASH)
VIO WIRE
