Manual a/c circuit for Suzuki Forenza I (2003-2008)

7 PNK 6 PNK WIRE A/C COMPRESSOR A/C COMPRESSOR RELAY A/C CONTROL SWITCH A/C PRESSURE TRANSDUCER (RIGHT SIDE OF ENGINE COMPT) A/C SWITCH BLK WIRE BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH) BLOWER MOTOR RESISTOR (BEHIND RIGHT SIDE OF DASH, NEAR BLOWER MOTOR) BLOWER MOTOR SWITCH BLOWER RELAY BLU WIRE BRN WIRE BRN/WHT WIRE ENGINE CONTROL MODULE (ECM) (CENTER REAR OF ENGINE COMPT) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE (ECT) SENSOR (FRONT OF ENGINE) ENGINE ROOM FUSE, RELAY BLOCK (LEFT FRONT OF ENGINE COMPT) FUSE 17 FUSE 22 FUSE 3 FUSE 4 FUSE 7 GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON I/P FUSE BLOCK (LEFT END OF DASH) FUSE 6 HOT IN ON OR START ILLUMINATION INTAKE MOTOR LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE OFF ORG/ WIRE PNK WIRE PNK/WHT WIRE RED WIRE SPLICE PACK 101 (IN ENGINE ROOM HARNESS, NEAR TOP OF TRANSMISSION) SPLICE PACK 203 (BEHIND CENTER OF DASH) VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

AUX COOLING FAN (BEHIND RIGHT SIDE OF RADIATOR) BLK WIRE BLU WIRE COOLING FAN CONTROL RELAY (IN ENGINE ROOM FUSE BLOCK) COOLING FAN HIGH RELAY COOLING FAN LOW RELAY ENGINE COMPT) ENGINE ROOM FUSE, RELAY BLOCK (LEFT FRONT OF FUSE 21 FUSE 6 FUSE 8 GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT W/ MAIN RELAY ENERGIZED LT BLU WIRE MAIN COOLING FAN (BEHIND LEFT SIDE OF RADIATOR) PNK/BLK WIRE VIO WIRE
