Rear wiper/washer circuit for Suzuki Esteem I (1995-2004)
Rear wiper/washer circuit
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
FUSE 28
HOT IN ON OR START
ILLUM
JUNCTION/ FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
ORG/ WIRE
REAR WASHER MOTOR (ON WASHER FLUID RESERVOIR)
REAR WIPER MOTOR (ON CENTER OF BACK DOOR)
REAR WIPER/WASHER SWITCH
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
WASHER SWITCH
WIPER SWITCH
YEL WIRE
YEL/RED WIRE
