Front wiper/washer circuit for Suzuki Esteem I (1995-2004)
Front wiper/washer circuit
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
FUSE 28
HI LO
HOT IN ON OR START
INT OFF
INTERMITTENT (INT) WIPER RELAY
JUNCTION/ FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
NCA WIRE
WASH
WINDSHIELD WASHER MOTOR (ON WASHER FLUID RESERVOIR)
WINDSHIELD WIPER MOTOR (ON CENTER OF FIREWALL)
WIPER/WASHER SWITCH (PART OF COMBINATION SWITCH)
YEL/BLU WIRE
YEL/RED WIRE
