Power window circuit for Suzuki Esteem I (1995-2004)
Power window circuit
AUTO CIRCUIT
BLK WIRE
BLU WIRE
CB 32
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/YEL WIRE
HOT IN ON
J/C (UNDER LEFT REAR SEAT)
JUNCTION/ FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SUB SWITCH
OFF
OFF LOCK
PNK WIRE
POWER WINDOW MAIN SWITCH
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT FRONT POWER WINDOW MOTOR
RIGHT FRONT POWER WINDOW SUB SWITCH
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SUB SWITCH
