Power top/sunroof circuits for Suzuki Esteem I (1995-2004)
Power top/sunroof circuits
BLK WIRE
BLU WIRE
CLOSE DOWN
CLOSE/ UP
FUSE 29
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT IN ON
JUNCTION/ FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
LIMIT SWITCH 1
LIMIT SWITCH 2
OFF
OPEN (UP)
OPEN/ DOWN
PTC THERMISTER
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SLIDE SWITCH
SLIDING ROOF CONTROLLER (ABOVE HEADLINER, ON CENTER FRONT OF ROOF)
SLIDING ROOF MOTOR (ABOVE HEADLINER, ON CENTER FRONT OF ROOF)
SLIDING ROOF SWITCH
TILT SWITCH
WHT WIRE
YEL WIRE
