Ground distribution circuit for Suzuki Esteem I (1995-2004)
Ground distribution circuit
ABS ACTUATOR UNIT, CONTROL MODULE
BATTERY
BLK WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLU WIRE
CIGARETTE LIGHTER, CLOCK, COMBINATION METER, REAR DEFOGGER SWITCH
COMBINATION METER, ENGINE CONTROL MODULE, IGNITOR 1, IGNITOR 2
COMPRESSOR FAN MOTOR, DUAL PRESSURE SWITCH
DIAGNOSIS CONNECTOR 1
DIAGNOSIS CONNECTOR 3, AIR BAG CONTROL MODULE
HEATER BLOWER MOTOR SWITCH, RADIO
HORN 1, HORN 2 (IF EQUIPPED), RADIATOR FAN MOTOR
RED/BLK WIRE
TRANSMISSION CONTROL MODULE (A/T)
WHT WIRE
