Anti-lock brake circuits for Suzuki Esteem I (1995-2004)

Anti-lock brake circuits

Get access

ABS ACTUATOR UNIT, CONTROL MODULE (LEFT REAR OF ENGINE COMPARTMENT) ABS IND. ABS WARNING LAMP RELAY (ON RELAY BOX) BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/ YEL WIRE BLU/YEL WIRE BRAKELIGHT SWITCH (ABOVE BRAKE PEDAL) BRN WIRE COMBINATION METER DATA LINK CONNECTOR (DLC) (PARTIAL) (RIGHT OF STEERING COLUMN) FUSE 23 GRN WIRE HOT AT ALL TIMES HOT IN ON OR START JUNCTION FUSE BLOCK (BEHIND LEFT SIDE OF DASH) FUSE 24 JUNCTION/ FUSE BLOCK (BEHIND LEFT SIDE OF DASH) LEFT FRONT SPEED SENSOR LEFT REAR SPEED SENSOR MAIN FUSE BOX (ON LEFT SIDE OF ENGINE COMPARTMENT) FUSE 4 ORG/ WIRE PNK/GRN WIRE PPL PPL DIAGNOSIS CONNECTOR 2 (ON RELAY BOX) RED WIRE RED/BLU WIRE RIGHT FRONT SPEED SENSOR RIGHT REAR SPEED SENSOR WHT WIRE
