Suzuki Esteem I (1995-2004) right front door lock motor, key switch Wiring diagrams

BACK DOOR LOCK MOTOR (WAGON ONLY) BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/YEL WIRE DOOR LOCK SWITCH HOT AT ALL TIMES JUNCTION FUSE BLOCK (BEHIND LEFT SIDE OF DASH) FUSE 27 LEFT FRONT DOOR LOCK MOTOR, KEY SWITCH LEFT REAR DOOR LOCK MOTOR OPEN CONNECTOR (PARTIAL) (BEHIND DASH, LEFT SIDE OF STEERING COLUMN) 1 2 8 POWER DOOR LOCK CONTROLLER (BEHIND DASH, LEFT OF STEERING COLUMN) RED WIRE RIGHT FRONT DOOR LOCK MOTOR, KEY SWITCH RIGHT REAR DOOR LOCK MOTOR YEL WIRE YEL/BLK WIRE

BACK DOOR LOCK MOTOR (WAGON ONLY) BACK DOOR SWITCH BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE DOOR LOCK SWITCH FUSE 11 FUSE 27 FUSE 28 GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN RUN, START J/C JUNCTION/ FUSE BLOCK (BEHIND LEFT SIDE OF DASH) KEYLESS RELAY 1 (BEHIND LEFT END OF DASH) KEYLESS RELAY 2 (BEHIND LOWER RIGHT CENTER OF DASH) LEFT FRONT DOOR LOCK MOTOR, KEY SWITCH LEFT FRONT DOOR SWITCH RIGHT FRONT DOOR SWITCH LEFT REAR DOOR LOCK MOTOR LEFT REAR DOOR SWITCH ORG/ WIRE ORG/BLK WIRE POWER DOOR LOCK,KEYLESS ENTRY CONTROLLER (BEHIND DASH, LEFT OF STEERING COLUMN) RED WIRE RELAY BOX (LEFT SIDE OF ENGINE COMPT) RIGHT FRONT DOOR LOCK MOTOR, KEY SWITCH RIGHT REAR DOOR LOCK MOTOR RIGHT REAR DOOR SWITCH TO WARNING SYSTEM WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
