Suzuki Esteem I (1995-2004) a/c switch, hazard warning light switch, mode actuator Wiring diagram
This page shows the only wiring diagram for the component.a/c switch, hazard warning light switch, mode actuator, which is found in the car Suzuki Esteem I (1995-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c switch, hazard warning light switch, mode actuator (1 of 1)
A/C AMPLIFIER, BACK-UP LIGHT SWITCH (M/T), TRANSMISSION RANGE SWITCH (A/T)
A/C CONDENSER FAN MOTOR RELAY, A/C MAGNETIC CLUTCH RELAY
A/C SWITCH, HAZARD WARNING LIGHT SWITCH, MODE ACTUATOR
BLK WIRE
BLU WIRE
BRN WIRE
CB 32
CIGARETTE LIGHTER
CLOCK, POWER MIRROR CONTROL SWITCH, RADIO
CLUTCH PEDAL POSITION SWITCH (M/T) OR TRANSMISSION RANGE SWITCH (A/T)
COMBINATION METER, CRUISE MAIN SWITCH
COMBINATION SWITCH (WINDSHIELD WIPER/WASHER)
FROM JUNCTION FUSE BLOCK (DIAGRAM 1 OF 2)
FUSE 21
FUSE 22
FUSE 23
FUSE 26
FUSE 28
FUSE 29
FUSE 30 (NOT USED)
FUSE 31
GRN WIRE
HEATER BLOWER MOTOR CONTROL RELAY, REAR DEFOGGER SWITCH
IGNITION SWITCH
JUNCTION FUSE BLOCK (WARNING CONTROLLER/ BUZZER)
JUNCTION/ FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
LOCK
LT GRN WIRE
REAR WIPER/ WASHER SWITCH, WINDSHIELD WIPER MOTOR
RED WIRE
RIGHT FRONT POWER WINDOW SUB SWITCH
SENSING, DIAGNOSTIC MODULE (SDM)
SLIDING ROOF CONTROLLER
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 2) -> A/C SWITCH, HAZARD WARNING LIGHT SWITCH, MODE ACTUATOR
