4.0l, differential lock circuit for Suzuki Equator I (2008-2012)
4.0l, differential lock circuit
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER DIFF LOCK IND
COMPUTER DATA LINES SYSTEM
DIFF LOCK CU (BACKUP)
DIFF LOCK SW DIFF LOCK IND DIFF LOCK SW OFF
DIFF LOCK SW ON GND DIFF LOCK LOW DIFF LOCK HIGH SSS
DIFFERENTIAL LOCK CONTROL UNIT
DIFFERENTIAL LOCK MODE SWITCH
DIFFERENTIAL LOCK POSITION SWITCH
DIFFERENTIAL LOCK SOLENOID
ENGINE COMPT)
FUSE 14 (UNDER RIGHT SIDE OF DASH)
FUSE 19
FUSE 3
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
PNK WIRE
RED WIRE
RED/YEL WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
