Suzuki Equator I (2008-2012) 4.0l, charging circuit

ALT C BATTERY BLK WIRE BLK/RED WIRE BLU WIRE CAN L CHARGE IND COMBINATION METER COMPUTER DATA LINES SYSTEM ENGINE COMPT) FUSE 14 FUSE BLOCK (J/B) (UNDER RIGHT SIDE OF DASH) FUSE, FUSIBLE LINK BOX (LEFT REAR ENGINE COMPT) FUSE 30 FUSIBLE LINK A FUSIBLE LINK BOX (BATTERY) FUSIBLE LINK F GENERATOR GRN WIRE HOT IN ON OR START LT BLU WIRE NCA WIRE PNK WIRE UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) WHT WIRE YEL WIRE
