2.5l, starting circuit for Suzuki Equator I (2008-2012)
2.5l, starting circuit
40 PNK WIRE
A/T
A/T ASSEMBLY
BATTERY
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CLUTCH INTERLOCK SWITCH
COMPUTER DATA LINES SYSTEM (4.0L)
CPU IGN SW GND CAN CAN (SIG)
FUSE, FUSIBLE LINK BOX (LEFT REAR ENGINE COMPT)
FUSIBLE LINK A
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK F
FUSIBLE LINK J
GRN WIRE
GRY WIRE
HOT W/ IGNITION RELAY ENERGIZED
IGNITION SWITCH
INH INH RELAY SW 3 SW 2 SW 4
INH INH SW 1
INHIBIT FUSE GND (PWR)
M/T
NCA WIRE
OFF
OFF ON
PARK/ NEUTRAL POSITION SWITCH
RED WIRE
STARTER MOTOR
STARTER RELAY
TRANSMISSION CONTROL MODULE (TCM)
WHT WIRE
WHT/GRN WIRE
