Door lock circuit, king cab for Suzuki Equator I (2008-2012)
Door lock circuit, king cab (1 of 2)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (RIGHT SIDE OF STEERING COLUMN UNDER DASH)
COMPUTER DATA LINES SYSTEM
FUSE 25
FUSE, FUSIBLE LINK BOX (LEFT REAR ENGINE COMPT)
FUSIBLE LINK G
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK FUSE 18 (J/B) (UNDER RIGHT SIDE OF DASH)
INSERTED
KEY SWITCH
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR LOWER SWITCH
LEFT REAR DOOR UPPER SWITCH
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
PPL 45 46 47 CDL LOCK SW CDL UNLOCK SW DOOR SW (DR)
PPL 6 7
RED WIRE
RED/YEL WIRE
REMOVED
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR LOWER SWITCH
RIGHT REAR DOOR UPPER SWITCH
WHT WIRE
YEL WIRE
Door lock circuit, king cab (2 of 2)
& N
ACTUATOR
BETWEEN FULL STROKE,
BLK WIRE
BLU WIRE
GRN WIRE
GRN/YEL WIRE
GRY WIRE
LEFT FRONT DOOR LOCK ASSEMBLY
LOCK
LOCK SWITCH FULL STROKE
LT BLU WIRE
LT GRN WIRE
MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
PNK WIRE
PPL
RED/WHT WIRE
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
UNLOCK
UNLOCK LOCK
UNLOCK SWITCH FULL STROKE
WHT WIRE
