Door lock circuit, crew cab for Suzuki Equator I (2008-2012)
Door lock circuit, crew cab (1 of 2)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (RIGHT SIDE OF STEERING COLUMN UNDER DASH)
COMPUTER DATA LINES SYSTEM
FUSE 18
FUSE 25
FUSE BLOCK (J/B) (UNDER RIGHT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (LEFT REAR ENGINE COMPT)
FUSIBLE LINK G
GRY WIRE
HOT AT ALL TIMES
INSERTED
KEY SWITCH
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LT BLU WIRE
LT GRN WIRE
PNK 48 47 DOOR SW (RL) DOOR SW (DR) WIRE
PNK WIRE
PPL
PPL 45 46 CDL LOCK SW CDL UNLOCK SW
RED WIRE
RED/YEL WIRE
REMOVED
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
WHT WIRE
YEL WIRE
Door lock circuit, crew cab (2 of 2)
& N
ACTUATOR
BETWEEN FULL STROKE,
BLK WIRE
BLU WIRE
GRN WIRE
GRN/YEL WIRE
GRY WIRE
LEFT FRONT DOOR LOCK ASSEMBLY
LEFT REAR DOOR LOCK ACTUATOR
LOCK
LOCK SWITCH FULL STROKE
LT BLU WIRE
LT GRN WIRE
MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
PNK WIRE
PPL
RED/WHT WIRE
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
RIGHT REAR DOOR LOCK ACTUATOR
UNLOCK
UNLOCK LOCK
UNLOCK SWITCH FULL STROKE
WHT WIRE
