Car Wiring Diagrams for Charging circuit for Suzuki Aerio I (2001-2007)

BATTERY BLK WIRE BLK/RED WIRE BLK/WHT WIRE CHARGE IND COMBINATION METER DRL CONTROLLER (BEHIND DASH, ABOVE LEFT SIDE OF GLOVE BOX) GENERATOR HOT IN ON OR START IG FUSE JUNCTION/ FUSE BOX MAIN FUSE BOX (ON LEFT SIDE OF ENGINE COMPT) FUSE 1 METER FUSE STARTING CIRCUIT WHT/BLU WIRE
