Shift interlock circuit, without cruise control for Suzuki Aerio I (2001-2007)
Shift interlock circuit, without cruise control
4 A/T CONTROLLER (BEHIND LEFT SIDE OF DASH, BELOW RADIO)
A/T SHIFT LEVER
A/T SHIFT LOCK SOLENOID RELAY (ON RELAY BOX)
BLK WIRE
BRAKELIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
FUSE 11 FUSE BOX (ON LEFT SIDE OF ENGINE COMPT) PNK WIRE
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INDIVIDUAL CIRCUIT FUSE BOX
MAIN
PNK WIRE
RED WIRE
SHIFT LOCK SOLENOID
TRANSAXLE RANGE SENSOR (LEFT FRONT OF ENGINE COMPARTMENT)
TURN/BACK FUSE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
