Subaru XV GP facelift (2015-2017) Radio circuit, hybrid w/o telematics

ANTENNA AUDIO (W/O NAVIGATION) NAVIGATION UNIT (W/ NAVIGATION) AUDIO BRACKET GROUND AUX INPUT TERMINAL (USB) BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE BRN/WHT WIRE BRN/YEL WIRE FUSE 24 FUSE 8 FUSE, RELAY BOX (F/B) GB-11 GRN WIRE GRY/GRN WIRE HOT AT ALL TIMES HOT IN ON OR ACC LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT SIDE TWEETER MAIN FUSE BOX (M/B) N/A NCA WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT SIDE TWEETER SATELLITE ANTENNA SHIELD VIO WIRE W/ SATELLITE ANTENNA WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLK WIRE YEL/RED WIRE

AUDIO (W/O NAVIGATION) NAVIGATION UNIT (W/ NAVIGATION) AUX INPUT TERMINAL BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE DOWN GB-11 GRY WIRE GRY/BLU WIRE GRY/GRN WIRE INSTRUMENT CLUSTER SYSTEM LEFT LIST MUTE/ENTER NAVIGATION SYSTEM NCA WIRE OFF HOOK ON HOOK PNK WIRE PNK/GRN WIRE REAR VIEW CAMERA CIRCUIT RED WIRE RED/BLK WIRE RETURN RIGHT ROLL CONNECTOR SATELLITE SWITCH SHIELD SOURCE SPOT MAP LIGHT (HANDSFREE MICROPHONE) TALK VDC CONTROL MODULE VIO WIRE VIO/RED WIRE W/ NAVIGATION W/ SUNROOF W/O NAVIGATION W/O NAVIGATION W/ NAVIGATION W/O SUNROOF WHT WIRE WHT/BLK WIRE YEL WIRE YEL/RED WIRE
