Courtesy lamps circuit, w/o hev for Subaru XV GP facelift (2015-2017)

BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BODY INTEGRATED UNIT DOOR FUSE 14 FUSE 15 FUSE 31 FUSE 8 FUSE, RELAY BOX (F/B) GB-11 GB-4 GB-5 GB-7 GB-8 GB-9 GRN/WHT WIRE GRN/YEL WIRE GRY/BLK WIRE HATCHBACK HOT AT ALL TIMES HOT IN ON OR ACC KEY ILLUMINATION LIGHT KEY WARNING SWITCH (W/O PUSH BUTTON START) (AT IGNITION SWITCH) LEFT "C" PILLAR) LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LT BLU WIRE LT GRN WIRE LUGGAGE ROOM LIGHT MAIN FUSE BOX (M/B) OFF ON OFF PNK SEDAN WIRE PNK WIRE PNK/BLU WIRE REAR GATE LATCH SWITCH RED WIRE RED/BLK WIRE RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH ROOM LIGHT SEDAN SPOT MAP LIGHT SPOT MAP LIGHT DIODE (RIGHT CENTER FRONT OF ROOF) STEREO CAMERA COVER (SPOT MAP LIGHT) TRUNK LID SWITCH TRUNK ROOM LIGHT VIO WIRE W/ SUNROOF WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL/BLU WIRE YEL/RED WIRE YEL/WHT WIRE
