Subaru XV GP facelift (2015-2017) daytime running light relay engine compartment relay holder Wiring diagram
This page shows the only wiring diagram for the component.daytime running light relay engine compartment relay holder, which is found in the car Subaru XV GP facelift (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram daytime running light relay engine compartment relay holder (1 of 1)
A/F OXYGEN SENSOR RELAY
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY INTEGRATED UNIT
DATA LINK CONNECTOR
DAYTIME RUNNING LIGHT RELAY ENGINE COMPARTMENT RELAY HOLDER
DRIVER SIDE RELAY HOLDER
ELECTRONIC THROTTLE CONTROL RELAY
ENGINE COMPARTMENT RELAY HOLDER
FROM FUSE 5 (DIAGRAM 1 OF 6)
FROM SLOW BLOW FUSE (DIAGRAM 1 OF 6)
FUEL PUMP RELAY
FUSE 1
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 8
FUSE HOLDER
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HIGH HEADLIGHT RELAY
HORN RELAY
HPCM
IG RELAY
LOW HEADLIGHT RELAY
LT GRN WIRE
MAIN FAN RELAY 1
MAIN RELAY
PASSENGER SIDE RELAY HOLDER
PASSENGER SIDE RELAY HOLDER (RIGHT CENTER OF DASH)
REAR DEFOGGER RELAY
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY HOLDER
ROOM LIGHT
SBF-1 FUSE
SBF-2 FUSE
SBF-3 FUSE
SBF-4 FUSE
SBF-5 FUSE
SBF-6 FUSE
SBF-7 FUSE
SBF-8 FUSE
SELF-SHUT RELAY
SPOT MAP LIGHT
SUB FAN RELAY
TCM
TO ACCESSORY RELAY (DIAGRAM 6 OF 6)
TO DRIVER SIDE RELAY HOLDER (DIAGRAM 3 OF 6)
TO FUSE HOLDER (DIAGRAM 6 OF 6)
TO FUSE, RELAY BOX (F/B) (DIAGRAM 3 OF 6)
TO FUSE, RELAY BOX (F/B) (DIAGRAM 4 OF 6)
TURN SIGNAL, HAZARD LIGHT MODULE
VDC CONTROL MODULE
W/ SUNROOF
W/O SUNROOF
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit, w/ hev (2 of 6) -> DAYTIME RUNNING LIGHT RELAY ENGINE COMPARTMENT RELAY HOLDER
