Subaru XV GP facelift (2015-2017) backup light Wiring diagrams

BACKUP LIGHT BACKUP LIGHT RELAY BLK WIRE BLU WIRE BRN WIRE BRN/YEL WIRE FUSE 18 FUSE, RELAY BOX (F/B) GB-3 GB-8 GB-9 GRN WIRE GRN/BLU WIRE INHIBITOR SWITCH LEFT REAR COMBINATION LIGHT NAVIGATION UNIT PASSENGER SIDE RELAY HOLDER REAR VIEW MIRROR) RED/GRN WIRE RELAY ENERGIZED RIGHT END OF DASH) RIGHT REAR COMBINATION LIGHT TRANSMISSION CONTROL MODULE W/ NAVIGATION W/O NAVIGATION YEL WIRE

4 DOOR 5 DOOR BACKUP LIGHT BACKUP LIGHT SWITCH BLK WIRE BLU WIRE BODY INTEGRATED UNIT BRN WIRE BRN/YEL WIRE CVT FUSE 18 FUSE, RELAY BOX (F/B) GB-10 GB-8 GB-9 GRN WIRE GRN/BLU WIRE INHIBITOR SWITCH LEFT REAR COMBINATION LAMP M/T M/T CVT NAVIGATION UNIT NCA WIRE REAR VIEW MIRROR) RELAY ENERGIZED RIGHT REAR COMBINATION LAMP TRAILER CONNECTOR WHT/BLK WIRE YEL WIRE

AUTO BACKUP LAMPS CIRCUIT BACKUP LIGHT BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BLU/YEL WIRE BODY INTEGRATED UNIT (LEFT END OF DASH) BRN WIRE CLEARANCE LIGHT COMBINATION SWITCH (LIGHTING SWITCH) DRIVER SIDE RELAY HOLDER FUSE FUSE 14 FUSE 15 FUSE 4 FUSE 8 FUSE HOLDER FUSE, RELAY BOX (F/B) GB-1 GB-2 GB-5 GB-8 GB-9 GRN WIRE GRY WIRE HIGH-MOUNTED STOPLIGHT (REAR SPOILER) HOT AT ALL TIMES HOT W/ KEYLESS ACCESS CONTROL MODULE LEFT FRONT COMBINATION LIGHT LEFT REAR COMBINATION LIGHT LT GRN WIRE MAIN FUSE BOX (M/B) NCA WIRE OFF PEDESTRIAN ALERT CONTROL MODULE PNK WIRE RED WIRE RED/BLK WIRE RIGHT FRONT COMBINATION LIGHT SIDE MARKER LIGHT STOP LIGHT TAIL RELAY TAIL- LIGHT TRANSMISSION CONTROL MODULE TURN LIGHT TURN SIGNAL LIGHT VDC CONTROL MODULE WHT WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE

BACKUP LAMPS CIRCUIT BACKUP LIGHT BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE COMBINATION METER COMPUTER FUSE 11 FUSE 14 FUSE, RELAY BOX (F/B) GB-11 GB-12 GB-5 GB-8 GRN WIRE GRN/BLU WIRE GRY WIRE HAZARD SWITCH HOT AT ALL TIMES LEFT LICENSE PLATE LIGHT LEFT OUTER MIRROR ASSEMBLY LEFT TURN SIGNAL LIGHT IND MAIN FUSE BOX (M/B) MICRO - NCA WIRE OFF PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RIGHT LICENSE PLATE LIGHT RIGHT OUTER MIRROR ASSEMBLY RIGHT REAR COMBINATION LIGHT RIGHT TURN SIGNAL LIGHT IND STOP LIGHT TAIL- LIGHT TURN LIGHT TURN SIGNAL LIGHT, HAZARD LIGHT MODULE TURN SIGNAL SWITCH VIO WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE

4 DOOR 5 DOOR BACKUP LIGHT BACKUP LIGHTS CIRCUIT BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE ECM (RIGHT SIDE OF DASH) FRONT FOG LIGHT RELAY GB-8 GB-9 (UNDER DRIVER'S SEAT) GRN WIRE GRY WIRE HIGH MOUNTED STOP LIGHT KEYLESS ACCESS CONTROL MODULE LEFT REAR COMBINATION LIGHT LIGHT LT GRN WIRE PASSENGER SIDE RELAY HOLDER PNK WIRE RED WIRE RED/BLK WIRE SIDE MARKER STOP LIGHT TAIL- LIGHT TURN SIG LIGHT VDC CONTROL MODULE W/ EYESIGHT W/ EYESIGHT W/O EYESIGHT W/ REAR SPOILER W/O REAR SPOILER WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE

4 DOOR 5 DOOR AUTO OFF BACKUP LIGHT BACKUP LIGHTS CIRCUIT BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE COMBINATION SWITCH COMPUTER DATA LINES SYSTEM FUSE 1 FUSE 12 FUSE, RELAY BOX (F/B) GB-5 GB-8 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START LEFT LICENSE PLATE LIGHT LIGHTING SWITCH NCA WIRE OFF PNK WIRE RED WIRE RED/BLK WIRE RIGHT LICENSE PLATE LIGHT RIGHT REAR COMBINATION LIGHT SIDE MARKER STEREO CAMERA STOP LIGHT TAIL- LIGHT TURN SIG LIGHT TURN SIGNAL SWITCH W/ EYESIGHT WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE
