Backup lamps circuit, with hev for Subaru XV GP (2011-2016)
Backup lamps circuit, with hev
BACKUP LIGHT
BACKUP LIGHT RELAY
BLK WIRE
BLU WIRE
BRN WIRE
BRN/YEL WIRE
FUSE 18
FUSE BLOCK (F/B) (LOWER LEFT SIDE OF DASH)
GB-3 (RIGHT END OF DASH)
GB-8 (UNDER FRONT PASSENGER'S SEAT)
GRN WIRE
GRN/BLU WIRE
INHIBITOR SWITCH (RIGHT SIDE OF TRANSMISSION)
LEFT REAR COMBINATION LIGHT
NAVIGATION UNIT
REARVIEW MIRROR)
RED/GRN WIRE
RELAY ENERGIZED
RIGHT REAR COMBINATION LIGHT
RIGHT RELAY HOLDER
TRANSMISSION CONTROL MODULE (LEFT END OF DASH)
W/ NAVIGATION
W/O NAVIGATION
YEL WIRE
