Subaru XV GP (2011-2016) w/ id code box w/o id code box Wiring diagrams
This page contains all the electrical diagrams for the component. w/ id code box w/o id code box, in which he is found in the car Subaru XV GP (2011-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
w/ id code box w/o id code box wiring diagram (1 of 2)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES
ENGINE COMPT)
ENGINE CONTROL MODULE (RIGHT SIDE OF DASH)
ENGINE CONTROLS SYSTEM
FUSE 12
FUSE 32
FUSE HOLDER
GB-4 (UNDER FRONT OF CENTER CONSOLE)
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK (F/B) (LOWER LEFT SIDE OF DASH) FUSE 8
ID CODE BOX (IF EQUIPPED)
KEYLESS ACCESS CONTROL MODULE (LEFT END OF DASH)
LT BLU WIRE
LT GRN WIRE
MAIN FUSE BOX (M/B) (LEFT REAR OF
ORG/ WIRE
PNK WIRE
PNK/BLU WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
SBF-8 FUSE
STEERING LOCK CONTROL MODULE (ON STEERING COLUMN)
STOP LIGHT, BRAKE SWITCH (TOP OF BRAKE PEDAL ASSEMBLY)
SYSTEM
VIO WIRE
W/ ID CODE BOX W/O ID CODE BOX
WHT WIRE
WHT/BLU WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Forced entry circuit, with hev (3 of 4) -> W/ ID CODE BOX W/O ID CODE BOX
