Subaru XV GP (2011-2016) image micro- computer Wiring diagrams
This page contains all the electrical diagrams for the component. image micro- computer, in which he is found in the car Subaru XV GP (2011-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
image micro- computer wiring diagram (1 of 2)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
CAN TRANSCEIVER, RECEIVER
COMPUTER DATA LINES SYSTEM
CONSTANT VOLTAGE CIRCUIT
FUSE
FUSE 5 SIDE OF DASH)
FUSE BLOCK (LOWER LEFT
GB-11 (UNDER RIGHT FRONT OF CENTER CONSOLE)
GB-4 (UNDER RIGHT FRONT OF CENTER CONSOLE)
GRN WIRE
GRN/BLU WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/SET
IG DETECTING CIRCUIT
IMAGE MICRO- COMPUTER
ISO AMPLIFIER
LT BLU WIRE
LT GRN WIRE
MAIN FUSE BOX (M/B) (LEFT REAR OF ENGINE COMPT)
MFD
MICRO COMPUTER
NCA WIRE
ORG/ WIRE
REARVIEW CAMERA (BOTTOM LEFT CENTER OF REAR GATE)
RED WIRE
ROLL CONNECTOR
SHIELD
STEERING SWITCH
VOL (-)
WHT WIRE
YEL WIRE
Go to component -> Rear view camera circuit, with hev -> IMAGE MICRO- COMPUTER
image micro- computer wiring diagram (2 of 2)
5 DOOR 4 DOOR
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
CAN TRANSCEIVER, RECEIVER
COMPUTER DATA LINES SYSTEM
CONSTANT VOLTAGE CIRCUIT
FUSE
FUSE 5
FUSE, RELAY BOX (F/B)
GB-11 (UNDER CENTER CONSOLE)
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/SET
IG DETECTING CIRCUIT
IMAGE MICRO- COMPUTER
ISO AMPLIFIER
LT BLU WIRE
LT GRN WIRE
MAIN FUSE BOX (M/B) (LEFT REAR OF ENGINE COMPT)
MFD
MICRO COMPUTER
NCA WIRE
ORG/ WIRE
REARVIEW CAMERA
RED WIRE
ROLL CONNECTOR
SHIELD
SHIELD (OR (OR (OR
STEERING SWITCH
VOL (-)
WHT WIRE
YEL WIRE
Go to component -> Rear view camera circuit, without hev with navigation & high grade mfd -> IMAGE MICRO- COMPUTER
