Subaru XV GP (2011-2016) a/c control panel mfd wiring diagram
This page shows the only wiring diagram for the component.a/c control panel mfd, which is found in the car Subaru XV GP (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
a/c control panel mfd wiring diagram (1 of 1)
A/C CONTROL PANEL MFD
AUDIO
AUDIO BRACKET GROUND
AUXILIARY INPUT TERMINAL (W/ USB)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BODY INTEGRATED UNIT
COMBINATION METER
DATA LINK CONNECTOR
ELECTRONIC THROTTLE CONTROL SHIELD
FRONT OXYGEN (A/F) SENSOR SHIELD
GB-11 (UNDER RIGHT FRONT OF CENTER CONSOLE)
GB-12 (UNDER LEFT FRONT OF CENTER CONSOLE)
GE-1 (TOP CENTER OF ENGINE)
GE-2 (TOP CENTER OF ENGINE)
GLOVE BOX ILLUMINATION LIGHT
HAZARD SWITCH
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
KNOCK SENSOR SHIELD
LEFT OUTER MIRROR ASSEMBLY
NAVIGATION UNIT
NCA WIRE
PASSENGERS DOOR LOCK SWITCH
POWER WINDOW MAIN SWITCH
REAR OXYGEN SENSOR SHIELD
REMOTE LEFT FRONT CONTROL POWER WINDOW MIRROR MOTOR SWITCH
RIGHT OUTER MIRROR ASSEMBLY
RIGHT RIGHT FRONT OUTER DOOR LOCK HANDLE ACTUATOR
W/ NAVIGATION
W/ PUSH BUTTON
W/O NAVIGATION
Go to component -> Ground distribution circuit, with hev (3 of 3) -> A/C CONTROL PANEL MFD
