Subaru WRX STI VA facelift (2016-2021) w/o amplifier w/ amplifier w/ tpms w/o tpms Wiring diagram
This page shows the only wiring diagram for the component.w/o amplifier w/ amplifier w/ tpms w/o tpms, which is found in the car Subaru WRX STI VA facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o amplifier w/ amplifier w/ tpms w/o tpms (1 of 1)
2.0L TURBO
AUDIO
BLK/BLU WIRE
BLK/WHT WIRE
BLOWER MOTOR RELAY
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY INTEGRATED UNIT
DATA COMMUNICATION MODULE
FROM MAIN FUSE BOX (M/B) (DIAGRAM 1 OF 5)
FRONT FOG LIGHT RELAY
FRONT POWER WINDOW SUB SWITCH
FUSE
FUSE 1
FUSE 10
FUSE 15
FUSE 17
FUSE 27
FUSE 28
FUSE 29
FUSE 3
FUSE 8
FUSE 9
FUSE HOLDER
FUSE, RELAY BOX (F/B)
GRN WIRE
GRN/WHT WIRE
IMMOBILIZER ANTENNA
KEYLESS ENTRY CONTROL MODULE
LEFT POWER SEAT
LEFT POWER SEAT SWITCH
LEFT VANITY MIRROR LIGHT
LUMBAR SWITCH
MAIN FUSE BOX (M/B)
MFD
N/A
NAVIGATION UNIT
NCA WIRE
PNK WIRE
POWER WINDOW CIRCUIT BREAKER
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
RED WIRE
RIGHT VANITY MIRROR LIGHT
ROOM LIGHT
SEAT HEATER RELAY
SPOT MAP LIGHT
STOP LIGHT, BRAKE SWITCH
SUNROOF UNIT
TPMS, KEYLESS ENTRY CONTROL MODULE
TRUNK ROOM LIGHT
W/ EYESIGHT
W/ NAVIGATION
W/ SUNROOF
W/ TPMS
W/O AMPLIFIER W/ AMPLIFIER W/ TPMS W/O TPMS
W/O EYESIGHT
W/O NAVIGATION
W/O SUNROOF
W/O TPMS
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
WIPER DEICER RELAY
Go to component -> Power distribution circuit, w/o push button start (2 of 5) -> W/O AMPLIFIER W/ AMPLIFIER W/ TPMS W/O TPMS
