Subaru Tribeca WX facelift (2007-2014) daytime running light control key lock module solenoid Wiring diagram
This page shows the only wiring diagram for the component.daytime running light control key lock module solenoid, which is found in the car Subaru Tribeca WX facelift (2007-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram daytime running light control key lock module solenoid (1 of 1)
AIR BAG CONTROL ACCESSORY MODULE RELAY 2
AT SELECT LEVER
AUTO A/C CONTROL MODULE
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRAKE FLUID LEVEL WIPER SWITCH DEICER PUMP
COMBINATION COMBINATION WASHER SWITCH SWITCH (WIPER) LEVEL (LIGHTING) SWITCH
DAYTIME RUNNING LIGHT CONTROL KEY LOCK MODULE SOLENOID
FROM GROUND GB-11 GB-4 (DIAGRAM 1 OF 3) (LEFT KICK PANEL)
FROM GROUND GB-3 (DIAGRAM 1 OF 3)
FRONT WIPER MOTOR
FUEL AIR BAG PUMP CONTROL RELAY UNIT MODULE
GB-5 (RIGHT END OF DASH)
GB-6 (CENTER OF DASH)
GB-7 (RIGHT KICK PANEL)
GRN WIRE
GRN/RED WIRE
GRY WIRE
GV (RIGHT SIDE OF ENGINE COMPT)
JOINT CONNECTOR
LEFT VANITY MIRROR ILLUMINATION LIGHT, HOME LINK
NCA WIRE
POWER TRANSISTOR
POWER WINDOW RELAY
PRESSURE SWITCH
REAR ENTER- TAINMENT (ROOF)
REAR VIEW CAMERA SHIELD
RIGHT VANITY MIRROR ILLUMINATION LIGHT
SEAT HEATER RELAY
SHIELD
SHORT CONNECTOR
SUNROOF CONTROL MODULE, MOTOR
TURN MIRROR SIGNAL, LOW BEAM HEATER HAZARD RELAY RELAY MODULE
VACUUM
VDC CONTROL MODULE
WIPER RELAY HOOD SWITCH
YAW RATE, LATERAL G SENSOR
Go to component -> Ground distribution circuit (3 of 3) -> DAYTIME RUNNING LIGHT CONTROL KEY LOCK MODULE SOLENOID
